Image 7-5
(Optional) Delete Destinations
1. Click on the blue button Delete Destination(s).
2. From the Name list click on the "x" space next to the output(s) you wish to delete.
3. Hit the red button Delete Destination(s) button. All of the selected Destination(s) will be removed from the list.
7.14 Configuration Menu > Layer optimization
General
In this procedure, the usage of Layers inside the EMP will be elaborated.
Prerequisite
• Ensure that you are familiar with the Configuration Menu. For details on this menu, please refer to
chapter "Configuration Menu", page 71, as well as previous chapter.
Layers in an Event Master Processor
In the system there are banks of Video Processing Units, VPS´s. These VPS´s service the total output raster
with layer resources. So 1, 4 or 8 outputs have the same number of layers to use as PIPs as the Mixing
Background Layer is on top of this.
The VPU ´s have a bandwidth setting that allow for a certain size of Resolution to enter the VPU and get
scaled. Currently we have SL / DL and 4K as settings allowing for mx 2048 x 1200 / 2560 x 1600 / 4096 x 2400
respectively.
The higher the resolution, the higher the bandwidth of the input and output of the scaler, or as we call it,
number of Links. (This can be found in the Aux Scaling settings too, where the highest setting is 8L, allowing
for 8 Links of 2K resolution).
System Setup
