EM GUI orientation
buttons align the Layer into the Screen Destination in which the center of the Layer is located. With the AOI
Markers set to "Off," the Layer alignment buttons align the Layer in the entire Screen Destination.
2.
Drag and drop Inputs from the Resources area to desired Destinations.
3.
Apply system-wide functions, User Keys, or Presets to Layers in the Screen Destinations.
-
Local Layers must be selected and effects applied in the appropriate Screen Destination. The EMTS
displays the result of the applied effects in the Screen Destination, but the Local Layers must be
selected and effects applied in the appropriate Screen Destination.
The Adjustment area lists Screen Layers that have been added to a Screen Destination.
More about AUX Destinations
Based on the Aux Capacity, the user can create AUX Destination on an output card. The AUX capacity defines
the Input capacity and scaler size of the AUX.
All output cards can be Auxes while only any 2 output cards with a total of 8 outputs can be Program outputs
Aux Capacity
Number of Outputs
2K (Single
Link)
Dual Link
4K
8L
Widescreen destinations can be downscaled by the Aux and based on the capacity it can
accommodate up to eight (8) outputs worth of widescreen.
Manipulating AUX Destinations in the Programming Menu
Use the Programming menu to manipulate AUX Destinations.
6.17 Configuration Menu > Adjustment >
Destination Configuration > Adjust Panel
General
Add, delete, and adjust Destinations with the Destination and Destination Adjust panels.
How to add Destination(s)
To assign an output configuration to a destination...
1.
Select the output configuration (Output tab).
2.
Click on the Add Screen Destinationor the Add Aux Destination button (Destination tab).
These buttons are highlighted in blue.
100
R5909934 /00
E2 Lite and EC-40
Max output Resolution
4
2
1
1
1920x1200
1920x1200
1920x1200
1920x1200
