8

Using the Configuration Menus

The configuration menus let you configure the VS-3232DN to best suit your needs.
There are two configuration menus:
•
Setup Menu—those that are accessed on a regular basis (for example,
storing setups and setting the delay), see
•
Config Menu—those that are accessed only occasionally (for example,
setting the interface or communication protocol), see
The following rules apply to the menu operation:
•
If no selection is made within approximately 15 seconds, the operation
times-out and the display reverts to the output/input display
•
At any point in the Menu, press ESC to move up one level or press
BREAKAWAY to exit the Menu altogether
•
At any point in the Menu, only buttons that are active light or flash
•
All of the procedures in this section assume that you are starting the
procedure from the standard, operational output/input display
8.1

Using the Setup Menu

The Setup Menu provides access to settings that are regularly changed and
comprises the following options:
•
1: inXX=>ALL, switching one input to all outputs (see
•
3: outXX=OFF, turning off an output (see
•
7: EDID, assignment to an output (see
•
9: Delay setting for an output (see
•
4: store setup XX, storing the setup in a preset (see
•
6: recall setup XX, recalling a preset (see
26
Section 8.1
Section 8.2
Section 8.1.2
Section 8.1.3 )
Section 8.1.4 )
Section 8.1.5
Section 8.1.6
VS-3232DN - Using the Configuration Menus
Section 8.1.1 )
)
)
)
