Chapter 4: Web configuration
The page includes the following fields:
Object
Type
Speed
Wave Length(nm)
Distance(m)
Temperature(C)
Voltage(V)
Current(mA)
TX power(dBm)
RX power(dBm)
Buttons
• Select the
SFP Monitor Event Alert
with the
Warning Temperature
SNMP Trap.
• Click to save changes.
Save
• Click to undo any changes made locally and revert to previously saved
Reset
values.
• Click to refresh the page immediately.
Refresh
• Select the
Auto-refresh
regular intervals.
96
Description
Displays the type of current SFP module. The possible types are:
• 1000Base-SX
• 1000Base-LX
• 100Base-FX
Displays the speed of the current SFP module. Different vendors'
SFP modules might show different speed information.
Displays the wavelength of current SFP module. Use this column to
check if the wavelength values of two nodes are matched when the
fiber connection fails.
Displays the supported distance of the current SFP module.
Displays the temperature of the current SFP module.
Displays the voltage of the current SFP module.
Displays the Ampere of the current SFP module.
Displays the TX power of the current SFP module.
Displays the RX power of the current SFP module.
check box. The switch will be in accordance
setting and allows users to record message out via
check box to enable an automatic refresh of the page at
