The page includes the following fields:
Object
Rx and Tx Discover
Rx and Tx Offer
Rx and Tx Request
Rx and Tx Decline
Rx and Tx ACK
Rx and Tx NAK
Rx and Tx Release
Rx and Tx Inform
Rx and Tx Lease
Query
Rx and Tx Lease
Unassigned
Rx and Tx Lease
Unknown
Rx and Tx Lease
Active
Buttons
• Click
Auto-refresh
every three seconds.
• Click to refresh the page immediately.
Refresh
• Click to clear the counters for the selected port.
Clear
IP source guard configuration
IP Source Guard is a secure feature used to restrict IP traffic on DHCP snooping
untrusted ports by filtering traffic based on the DHCP Snooping Table or manually
configured IP Source Bindings. It helps prevent IP spoofing attacks when a host tries to
spoof and use the IP address of another host. The IP Source Guard Configuration page
provides IP Source Guard-related configuration data.
NS3552-8P-2S-V2 User Manual
Description
The number of discover (option 53 with value 1) packets received and
transmitted.
The number of offer (option 53 with value 2) packets received and
transmitted.
The number of request (option 53 with value 3) packets received and
transmitted.
The number of decline (option 53 with value 4) packets received and
transmitted.
The number of ACK (option 53 with value 5) packets received and
transmitted.
The number of NAK (option 53 with value 6) packets received and
transmitted.
The number of release (option 53 with value 7) packets received and
transmitted.
The number of inform (option 53 with value 8) packets received and
transmitted.
The number of lease query (option 53 with value 10) packets received and
transmitted.
The number of lease unassigned (option 53 with value 11) packets received
and transmitted.
The number of lease unknown (option 53 with value 12) packets received
and transmitted.
The number of lease active (option 53 with value 13) packets received and
transmitted.
to refresh the page automatically. Automatic refresh occurs
