The page includes the following fields:
Object
Scheduler Mode
Queue Shaper
Enable
Queue Shaper Rate
Queue Shaper Unit
Queue Shaper
Excess
Queue Scheduler
Weight
Queue Scheduler
Percent
Port Shaper Enable
Port Shaper Rate
Port Shaper Unit
176
Description
Controls whether the scheduler mode is
switch port.
Controls whether the queue shaper is enabled for this queue on this switch
port.
Controls the rate for the queue shaper. The default value is 500. This value
is restricted to
100-1000000
when the Unit is Mbps.
13200
Controls the unit of measure for the queue shaper rate as
The default value is kbps.
Controls whether the queue is allowed to use excess bandwidth.
Controls the weight for this queue. The default value is 17. This value is
restricted to 1-100. This parameter only appears if Scheduler Mode is set to
Weighted.
Shows the weight in percent for this queue. This parameter only appears if
Scheduler Mode is set to Weighted.
Controls whether the port shaper is enabled for this switch port.
Controls the rate for the port shaper. The default value is 500. This value is
restricted to
100-1000000
when the Unit is Mbps.
13200
Controls the unit of measure for the port shaper rate as
default value is kbps.
Strict Priority
when the Unit is kbps, and it is restricted to 1-
when the Unit is kbps, and it is restricted to 1-
or on this
Weighted
or Mbps.
kbps
or Mbps. The
kbps
