Chapter 4: Web configuration
Object
TCP PSH
TCP ACK
TCP URG
Ethernet type parameters
Ethernet Type parameters can be configured when
Frame Type.
Object
EtherType Filter
Ethernet Type Value
Buttons
• Click to save changes.
Save
• Click to undo any changes made locally and revert to previously saved
Reset
values.
• Click to return to the previous page.
Cancel
ACL ports configuration
Configure the ACL parameters (ACE) of each switch port on the ACL Ports
Configuration page. These parameters will affect frames received on a port unless the
frame matches a specific ACE.
206
Description
Specify the TCP "Push Function" (PSH) value for this ACE.
0: TCP frames where the PSH field is set must not be able to match this
entry.
1: TCP frames where the PSH field is set must be able to match this entry.
Any: Any value is allowed ("don't-care").
Specify the TCP "Acknowledgment field significant" (ACK) value for this
ACE.
0: TCP frames where the ACK field is set must not be able to match this
entry.
1: TCP frames where the ACK field is set must be able to match this entry.
Any: Any value is allowed ("don't-care").
Specify the TCP "Urgent Pointer field significant" (URG) value for this ACE.
0: TCP frames where the URG field is set must not be able to match this
entry.
1: TCP frames where the URG field is set must be able to match this entry.
Any: Any value is allowed ("don't-care").
Description
Specify the Ethernet type filter for this ACE.
Any: No EtherType filter is specified (EtherType filter status is "don't-care").
Specific: If you want to filter a specific EtherType filter with this ACE, you
can enter a specific EtherType value. A field for entering a EtherType value
appears.
When is selected for the EtherType filter, you can enter a specific
Specific
EtherType value.
The allowed range is
0x600
0x806(ARP) and 0x86DD(IPv6). A frame that hits this ACE matches this
EtherType value.
Ethernet Type
to but excluding 0x800(IPv4),
0xFFFF
is selected as the
