The page includes the following fields:
Object
Delete
ID
Desc
Type
Community
Event Last Time
Buttons
• Click
Add New Entry
• Click to save changes.
Save
• Click to undo any changes made locally and revert to previously saved
Reset
values.
RMON event status
The RMON Event Overview page provides an overview of RMON Event table entries.
Each page shows up to 99 entries from the Event table (default is 20 entries per page).
The range of entries per page can be typed into the
fields. When initially accessing the page, it shows the first 20 entries
entries per page
from the beginning of the Event table. The first entry shown will be the one with the
lowest ID found in the Event table
NS3552-8P-2S-V2 User Manual
Description
Select to delete the entry. It will be deleted during the next save.
Indicates the index of the entry. The range is from 1 to 65535.
Indicates the event. The string length is from 0 to 127, default is a null string.
Indicates the notification of the event. The possible types are:
none: The total number of octets received on the interface, including framing
characters.
log: The number of unicast packets delivered to a higher-layer protocol.
snmptrap: The number of broadcast and multicast packets delivered to a
higher-layer protocol.
logandtrap: The number of inbound packets that are discarded when the
packets are normal.
Specify the community when trap is sent. The string length is from 0 to 127,
default is "public."
Indicates the value of sysUpTime at the time this event entry last generated
an event.
to add a new community entry.
Chapter 4: Web configuration
Start from Control Index
