Chapter 4: Web configuration
Object
Frame Type
Action
Rate Limiter
Port Redirect
Counter
Modification Buttons
Buttons
• Select the Auto-refresh
refresh occurs every three seconds.
• Click Refresh to refresh the page.
Clear
• Click to clear the counters.
Remove All
• Click
ACE configuration
Configure an ACE (Access Control Entry) on the ACE Configuration page. An ACE
consists of several parameters that vary according to the frame type selected. First
select the ingress port for the ACE, and then select the frame type. Different parameter
options appear depending on the frame type selected. A frame that hits this ACE
matches the configuration that is defined here.
198
Description
Indicates the frame type of the ACE. Possible values are:
Any: The ACE matches any frame type.
EType: The ACE matches Ethernet Type frames. Note that an Ethernet
Type based ACE will not get matched by IP and ARP frames.
ARP: The ACE matches ARP/RARP frames.
IPv4: The ACE matches all IPv4 frames.
IPv4/ICMP: The ACE matches IPv4 frames with ICMP protocol.
IPv4/UDP: The ACE matches IPv4 frames with UDP protocol.
IPv4/TCP: The ACE matches IPv4 frames with TCP protocol.
IPv4/Other: The ACE matches IPv4 frames, which are not ICMP/UDP/TCP.
IPv6: The ACE matches all IPv6 standard frames.
Indicates the forwarding action of the ACE.
Permit: Frames matching the ACE may be forwarded and learned.
Deny: Frames matching the ACE are dropped.
Indicates the rate limiter number of the ACE. The allowed range is 1 to 16.
When Disabled is shown, the rate limiter operation is disabled.
Indicates the port redirect operation of the ACE. Frames matching the ACE
are redirected to the port number.
The allowed values are
is shown, the port redirect operation is disabled.
The counter indicates the number of times the ACE was hit by a frame.
Modify each ACE (Access Control Entry) in the table using the following
buttons:
: Inserts a new ACE before the current row.
: Edits the ACE row.
: Moves the ACE up the list.
: Moves the ACE down the list.
: Deletes the ACE.
: The lowest plus sign adds a new entry at the bottom of the ACE listings.
check box to refresh the page automatically. Automatic
to remove all ACEs.
Disabled or a specific port number. When Disabled
