Object
Buttons
• Select
VLAN Users
• Select the
Auto-refresh
refresh occurs every three seconds.
• Click to refresh the page immediately.
Refresh
• Click to update the table starting from the first entry in the VLAN Table (i.e., the
I<<
entry with the lowest VLAN ID).
• Click to update the table, starting with the entry after the last entry currently
>>
displayed.
VLAN port status
The VLAN Port Status for Static User page provides VLAN port status.
NS3552-8P-2S-V2 User Manual
Description
Authentication Server.
MVR: MVR is used to eliminate the need to duplicate multicast traffic
for subscribers in each VLAN. Multicast traffic for all channels is sent
only on a single (multicast) VLAN.
VLAN: Voice VLAN is a VLAN configured specially for voice
Voice
traffic typically originating from IP phones.
MSTP: The 802.1s Multiple Spanning Tree protocol (MSTP) uses
VLANs to create multiple spanning trees in a network, which
significantly improves network resource utilization while maintaining a
loop-free environment.
from the
Combined
check box to refresh the page automatically. Automatic
drop-down list.
Chapter 4: Web configuration
117
