Receive error counters
Object
Rx Drops
Rx CRC/Alignment
Rx Undersize
Rx Oversize
Rx Fragments
Rx Jabber
Rx Filtered
1 Short frames are frames that are smaller than 64 bytes.
2
Long frames are frames that are longer than the configured maximum frame length for this port.
Transmit error counters
Object
Tx Drops
Tx Late/Exc. Coll.
Buttons
• Click to refresh the page immediately.
Refresh
• Click to clear the counters for all ports.
Clear
• Select the
Auto-refresh
regular intervals.
SFP module information
You can check the physical or operational status of an SFP module via the SFP Module
Information page. This page shows the operational status such as the transceiver type,
speed, wavelength, optical output power, optical input power, temperature, laser bias
current, and transceiver supply voltage in real time. You can also use the port number
hyperlinks to check the statistics on a specific interface.
NS3552-8P-2S-V2 User Manual
Description
The number of frames dropped due to lack of receive buffers or
egress congestion.
The number of frames received with CRC or alignment errors.
The number of short frames received with valid CRC.
1
The number of long frames received with valid CRC.
2
The number of short frames received with invalid CRC.
1
The number of long frames received with invalid CRC.
2
The number of received frames filtered by the forwarding process.
Description
The number of frames dropped due to output buffer congestion.
The number of frames dropped due to excessive or late collisions.
check box to enable an automatic refresh of the page at
