Chapter 4: Web configuration
Object
IP Option
SIP Filter
SIP Address
SIP Mask
DIP Filter
DIP Address
DIP Mask
ICMP parameters
Object
ICMP Type Filter
ICMP Type Value
ICMP Code Filter
ICMP Code Value
204
Description
Specify the options flag setting for this ACE.
No: IPv4 frames where the options flag is set must not be able to match this
entry.
Yes: IPv4 frames where the options flag is set must be able to match this
entry.
Any: Any value is allowed ("don't-care").
Specify the source IP filter for this ACE.
Any: No source IP filter is specified. (Source IP filter is "don't-care").
Host: Source IP filter is set to Host. Specify the source IP address in the SIP
Address field that appears.
Network: Source IP filter is set to Network. Specify the source IP address
and source IP mask in the SIP Address and SIP Mask fields that appear.
When or
Host Network
specific SIP address in dotted decimal notation.
When is selected for the source IP filter, you can enter a specific
Network
SIP mask in dotted decimal notation.
Specify the destination IP filter for this ACE.
Any: No destination IP filter is specified. (Destination IP filter is "don't-care").
Host: Destination IP filter is set to Host. Specify the destination IP address
in the DIP Address field that appears.
Network: Destination IP filter is set to Network. Specify the destination IP
address and destination IP mask in the DIP Address and DIP Mask fields
that appear.
When or
Host Network
a specific DIP address in dotted decimal notation.
When is selected for the destination IP filter, you can enter a
Network
specific DIP mask in dotted decimal notation.
Description
Specify the ICMP filter for this ACE.
Any: No ICMP filter is specified (ICMP filter status is "don't-care").
Specific: To filter a specific ICMP filter with this ACE, you can enter a
specific ICMP value. A field for entering an ICMP value appears.
When is selected for the ICMP filter, you can enter a specific ICMP
Specific
value. The allowed range is
ICMP value.
Specify the ICMP code filter for this ACE.
Any: No ICMP code filter is specified (ICMP code filter status is "don't-care").
Specific: To filter a specific ICMP code filter with this ACE, you can enter a
specific ICMP code value. A field for entering an ICMP code value appears.
When is selected for the ICMP code filter, you can enter a specific
Specific
ICMP code value.
The allowed range is
0
code value.
is selected for the source IP filter, you can enter a
is selected for the destination IP filter, you can enter
to 255. A frame that hits this ACE matches this
0
to 255. A frame that hits this ACE matches this ICMP
