Chapter 4: Web configuration
The page includes the following fields:
Object
Port
PVID
Untag VID
Ingress Filtering
Accept Frame Type
Link Type
Q-in-Q Mode
Set Out layer VLAN
tag ether type
The port must be a member of the same VLAN as the Port VLAN ID.
Note:
Buttons
• Click to save changes.
Save
• Click to undo any changes made locally and revert to previously saved
Reset
values.
114
Description
This is the logical port number for this row.
Allows to assign PVID to selected port. The range for the PVID is 1-
4094.
The PVID will be inserted into all untagged frames entering the
ingress port. The PVID must be the same as the VLAN ID in that the
port belongs to VLAN group, or the untagged traffic will be dropped.
Allows user to set the port to remove default VID. This option could be
edited when the Link Type is selected as Tagged.
Enable ingress filtering for a port byselecting this check box. This
parameter affects VLAN ingress processing. If ingress filtering is
enabled and the ingress port is not a member of the classified VLAN
of the frame, the frame is discarded. By default, ingress filtering is
disabled (no checkmark).
Determines whether the port accepts all frames or only tagged
frames. This parameter affects VLAN ingress processing. If the port
only accepts tagged frames, untagged frames received on the port
are discarded. By default, the field is set to All.
Allow 802.1Q Untagged or Tagged VLAN for selected port.
When adding a VLAN to selected port, it tells the switch whether to
keep or remove the tag from a frame on egress.
Untag: outgoing frames without VLAN-Tagged.
Tagged: outgoing frames with VLAN-Tagged.
Sets the industrial managed switch to QinQ mode, and allows the
QinQ tunnel port to be configured. The default is for the industrial
managed switch to function in
Disable: The port operates in its normal VLAN mode. (This is the
default.)
Port: Configures IEEE 802.1Q tunneling (QinQ) for an uplink
MAN
port to another device within the service provider network.
Port: Configures IEEE 802.1Q tunneling (QinQ) for a client
Customer
access port to segregate and preserve customer VLAN IDs for traffic
crossing the service provider network.
The Tag Protocol Identifier (TPID) specifies the ether type of incoming
packets on a tunnel access port.
Tag: 8100
802.1Q
Tag: 88A8
vMAN
Default: 802.1Q Tag
mode.
Disable
