Selected counters
Object
Selected Counters
Attached MAC address
Object
Identity
MAC Address
VLAN ID
State
Last Authentication
Buttons
•
Select the
Auto-refresh
refresh occurs every three seconds.
•
Click
to refresh the page immediately.
Refresh
•
Click
to clear the counters for the selected port. This button is available in the
Clear
following modes:
•
Force Authorized
•
Force Unauthorized
•
Port-based 802.1X
NS3552-8P-2S-V2 User Manual
Description
The Selected Counters table is visible when the port is one of the following
administrative states:
Multi 802.1X
MAC-based
Auth.
The table is identical to and is placed next to the Port Counters table, and
will be empty if no MAC address is currently selected. To populate the table,
select one of the attached MAC Addresses from the table below.
Description
Shows the identity of the supplicant, as received in the Response Identity
EAPOL frame.
Clicking the link causes the supplicant's EAPOL and back end server
counters to be shown in the Selected Counters table. If no supplicants are
attached, it shows No supplicants attached.
This column is not available for MAC-based Auth.
For Multi 802.1X, this column holds the MAC address of the attached
supplicant.
For MAC-based Auth., this column holds the MAC address of the attached
client.
Clicking the link causes the client's back end server counters to be shown in
the Selected Counters table. If no clients are attached, it shows no clients
attached.
This column holds the VLAN ID that the corresponding client is currently
secured through the Port Security module.
The client can either be authenticated or unauthenticated. In the
authenticated state, it is allowed to forward frames on the port, and in the
unauthenticated state, it is blocked. As long as the back end server hasn't
successfully authenticated the client, it is unauthenticated. If an
authentication fails for one or the other reason, the client will remain in the
unauthenticated state for Hold Time seconds.
Shows the date and time of the last authentication of the client (successful
as well as unsuccessful).
check box to refresh the page automatically. Automatic
Chapter 4: Web configuration
227
