Chapter 4: Web configuration
Client statistics:
Object
Transmit to Client
Transmit Error
Receive from Client
Receive Agent Option
Replace Agent Option
Keep Agent Option
Drop Agent Option
Buttons
•
Select the
Auto-refresh
refresh occurs every three seconds.
•
Click
Refresh
to immediately refresh the page.
•
Click
Clear
to clear all statistics.
CPU load
This page displays the CPU load using an SVG graph. The load is measured as
average over the last 100 ms, 1 second, and 10 second intervals. The last 120 samples
are graphed, and the last numbers are displayed as text as well. To display the SVG
graph, the browser must support the SVG format. Consult the SVG Wiki for more
information on browser support as a plugin may be required.
56
Description
The number of packets relayed from server to client.
The number of packets erroneously sent to servers.
The number of packets received from the server.
The number of packets received with the relay agent information
option.
The number of packets received is replaced with the relay agent
information option.
The number of packets received is kept with the relay agent
information option.
The number of packets received is dropped with the relay agent
information option.
check box to refresh the page automatically. Automatic
NS3552-8P-2S-V2 User Manual
