Chapter 4: Web configuration
The page includes the following fields:
Object
VLAN ID
Group
Port
Mode
Source Address
Type
Hardware
Filter/Switch
Buttons
• Select
Auto-refresh
• Click to refresh the table starting from the input fields.
Refresh
• Click to update the table starting from the first entry in the MLD SFM information
I<<
table.
• Click to update the table, starting with the entry after the last entry currently
>>
shown.
MVR (Multicast VLAN Registration)
The MVR feature enables multicast traffic forwarding on the Multicast VLANs.
• In a multicast television application, a computer or a network television or a set-top
box can receive a multicast stream.
• Multiple set-top boxes or computers can be connected to one subscriber port, which
is a switch port configured as an MVR receiver port. When a subscriber selects a
channel, the set-top box or computer sends an IGMP/MLD report message to
Switch A to join the appropriate multicast group address.
• Uplink ports that send and receive multicast data to and from the multicast VLAN
are called MVR source ports.
A maximum of eight MVR VLANs with corresponding channel settings can be created
for each multicast VLAN. A maximum of 256 group addresses are available for channel
settings.
168
Description
VLAN ID of the group.
Group address of the group shown.
Switch port number.
Indicates the filtering mode maintained per basis (VLAN ID, port number,
Group Address). It can be either
IP Address of the source. Currently, the system limits the total number of IP
source addresses for filtering to 128.
Indicates the type. It can be either
Indicates if the data plane destined to the specific group address from the
source IPv4 address can be accomodated by the chip.
to automatically refresh the page every three seconds.
or Exclude.
Include
or Deny.
Allow
