VLAN entries and assigning the entries to different ports. This page shows only static
entries.
The page includes the following fields:
Object
Delete
MAC Address
VLAN ID
Port Members
Adding a New MAC-based
VLAN
Buttons
• Click
Add New Entry
• Click to save changes.
Save
• Click to undo any changes made locally and revert to previously saved
Reset
values.
• Select the
Auto-refresh
refresh occurs every three seconds.
• Click to refresh the page immediately.
Refresh
NS3552-8P-2S-V2 User Manual
Description
To delete a MAC-based VLAN entry, select this box and click Save.
Indicates the MAC address.
Indicates the VLAN ID.
A row of check boxes for each port appears for each MAC-based
VLAN entry. To include a port in a MAC-based VLAN, select the
check box. To remove or exclude the port from the MAC-based
VLAN, make sure the box is deselected. By default, no ports are
members, and all boxes are deselected.
Click
Add New Entry
empty row is added to the table, and the MAC-based VLAN entry can
be configured as needed. Any unicast MAC address can be
configured for the MAC-based VLAN entry. No broadcast or multicast
MAC addresses are allowed. Legal values for a VLAN ID are 1
through 4095.
The MAC-based VLAN entry is enabled when clicking Save. A MAC-
based VLAN without any port members will be deleted when clicking
Save. The button can be used to undo the addition of new
Delete
MAC-based VLANs.
to add a new MAC-based VLAN entry
check box to refresh the page automatically. Automatic
to add a new MAC-based VLAN entry. An
Chapter 4: Web configuration
