Tx
These back end (RADIUS) frame counters are available for the following
Back end Server
administrative states:
Counters
Port-based 802.1X
Single 802.1X
Multi 802.1X
MAC-based
Direction
Rx
Rx
Rx
Rx
NS3552-8P-2S-V2 User Manual
dot1xAuthEapolReqFr
Requests
amesTx
Auth.
Name
IEEE Name
dot1xAuthBack
Access
endAccessChallenges
Challenge
s
dot1xAuthBack
Other
endOtherRequestsTo
Requests
Supplicant
dot1xAuthBack
Auth.
endAuthSuccesses
Successe
s
dot1xAuthBack
Auth.
endAuthFails
Failures
Chapter 4: Web configuration
The number of valid
EAPOL Request frames
(other than Request
Identity frames) that have
been transmitted by the
switch.
Description
802.1X-based:
Counts the number of
times that the switch
receives the first request
from the back end server
following the first response
from the supplicant.
Indicates that the back end
server has communication
with the switch.
MAC-based:
Counts all Access
Challenges received from
the back end server for this
port (left-most table) or
client (right-most table).
802.1X-based:
Counts the number of
times that the switch sends
an EAP Request packet
following the first to the
supplicant. Indicates that
the back end server chose
an EAP-method.
MAC-based:
Not applicable.
802.1X- and MAC-based:
Counts the number of
times that the switch
receives a success
indication. Indicates that
the supplicant/client has
successfully authenticated
to the back end server.
802.1X- and MAC-based:
Counts the number of
times that the switch
receives a failure message.
This indicates that the
supplicant/client has not
225
