Interlogix NS3552-8P-2S-V2 User Manual page 209

The page includes the following fields:
Object
Port
Policy ID
Action
Rate Limiter ID
Port Redirect
Mirror
Logging
Shutdown
NS3552-8P-2S-V2 User Manual
Description
The logical port for the settings contained in the same row.
Select the policy to apply to this port. The allowed values are
The default value is 0.
Select whether forwarding is permitted (Permit) or denied (Deny).
The default value is Permit.
setting.
Select which rate limiter to apply on this port. Selections include
(default value) or the values
specific setting.
Select which port frames are redirected on. Selections include
(default value)or a specific port number and it can't be set when action is
permitted. means all ports will have one specific setting.
All
Specify the mirror operation of this port. The allowed values are:
Enabled: Frames received on the port are mirrored.
Disabled: Frames received on the port are not mirrored.
The default value is Disabled.
means all ports will have one specific setting.
All
Specify the logging operation of this port. Selections include:
Enabled: Frames received on the port are stored in the System Log.
Disabled: Frames received on the port are not logged.
The default value is Disabled.
Note: The System Log memory size and logging rate are limited.
means all ports will have one specific setting.
All
Specify the port shut down operation of this port. Selections include:
Enabled: If a frame is received on the port, the port will be disabled.
Disabled: Port shut down is disabled.
The default value is Disabled.
setting.
means all ports will have one specific
All
through 16. means all ports will have one
1 All
means all ports will have one specific
All
Chapter 4: Web configuration
through 255.
0
Disabled
Disabled
207
