Instance state
Object
Protection State
Port 0
Port 1
Transmit APS
Port 0 Receive APS
Port 1 Receive APS
WTR Remaining
RPL Un-blocked
No APS Received
Port 0 Block Status
Port 1 Block Status
FOP Alarm
Buttons
• Select the
Auto-refresh
refresh occurs every six seconds.
• Click to refresh the page immediately.
Refresh
• Click to save changes.
Save
• Click to undo any changes made locally and revert to previously saved
Reset
values.
NS3552-8P-2S-V2 User Manual
Description
ERPS state according to the state transition tables in G.8032.
OK: State of East port is OK.
SF: State of East port is Signal Fail.
OK: State of West port is OK.
SF: State of West port is Signal Fail.
The transmitted APS according to the state transition tables in G.8032.
The received APS on Port 0 according to the state transition tables in
G.8032.
The received APS on Port 1 according to the state transition tables in
G.8032.
Remaining WTR timeout in milliseconds.
APS is received on the working flow.
RAPS PDU is not received from the other end.
Block status for Port 0 (both traffic and R-APS block status). R-APS channel
is never blocked on sub-rings without a virtual channel.
Block status for Port 1 (both traffic and R-APS block status). R-APS channel
is never blocked on sub-rings without a virtual channel.
Failure of Protocol Defect (FOP) status. If FOP is detected, a red LED
illuminates, otherwise a green LED illuminates.
check box to refresh the page automatically. Automaticc
