Chapter 4: Web configuration
Tx
Information about the last supplicant/client that attempted to authenticate. This
Last
information is available for the following administrative states:
Supplicant/Client
Info
Port-based 802.1X
Single 802.1X
Multi 802.1X
MAC-based
Name
MAC Address
VLAN ID
Version
Identity
226
dot1xAuthBack
Response
endResponses
s
Auth.
IEEE Name
dot1xAuthLastEapo
lFrameSource
-
dot1xAuthLastEapo
lFrameVersion
-
authenticated to the back
end server.
802.1X-based:
Counts the number of
times that the switch
attempts to send a
supplicant's first response
packet to the back end
server. Indicates the switch
attempted communication
with the back end server.
Possible retransmissions
are not counted.
MAC-based:
Counts all the back end
server packets sent from
the switch towards the
back end server for a given
port (left-most table) or
client (right-most table).
Possible retransmissions
are not counted.
Description
The MAC address of the last
supplicant/client.
The VLAN ID on which the last frame from
the last supplicant/client was received.
802.1X-based:
The protocol version number carried in the
most recently received EAPOL frame.
MAC-based:
Not applicable.
802.1X-based:
The user name (supplicant identity) carried
in the most recently received Response
Identity EAPOL frame.
MAC-based:
Not applicable.
