• Click to update the table starting from the first entry in the MAC-based VLAN
I<<
table.
• Click to update the table, starting with the entry after the last entry currently
>>
displayed.
MAC-based VLAN status
The MAC-based VLAN Membership Status page shows MAC-based VLAN entries
configured by various MAC-based VLAN users
The page includes the following fields:
Object
MAC Address
VLAN ID
Port Members
Buttons
• Select the
Auto-refresh
refresh occurs every three seconds.
• Click to refresh the page immediately.
Refresh
Protocol-based VLAN
The Protocol to Group Mapping Table page permits the addition of new protocols to the
Group Name (unique for each Group) mapping entries, and allows you to see and
delete entries already mapped for the switch.
128
Description
Indicates the MAC address.
Indicates the VLAN ID.
Port members of the MAC-based VLAN entry.
check box to refresh the page automatically. Automatic
