The page includes the following fields:
Object
DSCP
Trust
QoS Class
DPL
Buttons
•
Click
to save changes.
Save
•
Click
to undo any changes made locally and revert to previously saved
Reset
values.
NS3552-8P-2S-V2 User Manual
Description
Maximum number of supported DSCP values is 64.
Controls whether a specific DSCP value is trusted. Only frames with trusted
DSCP values are mapped to a specific QoS class and Drop Precedence
Level. Frames with untrusted DSCP values are treated as a non-IP frame.
QoS Class values can be between 0-7.
Drop Precedence Level (0-1)
Chapter 4: Web configuration
183
