Interlogix NS3552-8P-2S-V2 User Manual page 17

Jumbo Frame
Reset Button
Enclosure
Installation
Connector
Alarm
Digital Input
Digital Output
LED
Dimensions
Weight
Power Requirement
Power Consumption
ESD Protection
EFT Protection
Power over Ethernet
PoE Standard
PoE Power Supply Type
NS3552-8P-2S-V2 User Manual
Back pressure for half-duplex
9K bytes
< 5 seconds: System reboot
> 5 seconds: Factory Default
IP30 aluminum case
DIN rail kit and wall-mount kit
Removable 6-pin terminal block for power input
Pin 1/2 for Power 1, Pin 3/4 for fault alarm, Pin 5/6 for Power 2
Removable 6-pin terminal block for DI/DO interface
Pin 1/2 for DI 1 & 2, Pin 3/4 for DO 1 & 2, Pin 5/6 for GND
One relay output for power failure. Alarm relay current carry ability:
1A @ 24 VDC
Two Digital Inputs (DI)
Level 0: -24~2.1 V (±0.1 V)
Level 1: 2.1~24 V (±0.1 V)
Input load to 24 VDC, 10 mA max.
Two Digital Outputs (DO)
Open collector to 24 VDC, 100 mA max.
System:
Power 1 (Green)
Power 2 (Green)
Fault Alarm (Green)
Ring (Green)
Ring Owner (Green)
Per 10/100/1000T RJ45 Ports:
PoE in-use (Orange)
1000 LNK/ACT (Green)
Per SFP Interface:
100 LNK/ACT (Orange)
1000 LNK/ACT (Green)
152 x 107 x 72 mm
1.684 kg
DC 48 V
31.9 W / 108.78 BTU (full loading without PoE function)
306 W / 1043.46 BTU (full loading with PoE function)
6K VDC
6K VDC
IEEE 802.3af/802.3at PoE / PSE
End-span
Chapter 1: Introduction
15
