The page includes the following fields:
Object
VLAN ID
Group
Port
Mode
Source Address
Type
Hardware
Filter/Switch
Buttons
• Select
Auto-refresh
• Click to refresh the table starting from the input fields.
Refresh
• Click to update the table starting from the first entry in the IGMP group table.
I<<
• Click to update the table, starting with the entry after the last entry currently
>>
shown.
MLD snooping configuration
The MLD Snooping Configuration page provides MLD snooping-related configuration.
NS3552-8P-2S-V2 User Manual
Description
VLAN ID of the group.
Group address of the group shown.
Switch port number.
Indicates the filtering mode maintained per (VLAN ID, port number, Group
Address) basis. It can be either Include or Exclude.
IP Address of the source. Currently, system limits the total number of IP
source addresses for filtering to 128.
Indicates the type. It can be either
Indicates if the data plane destined to the specific group address from the
source IPv4 address can be accomodated by the chip.
to automatically refresh the page every three seconds.
Chapter 4: Web configuration
or Deny.
Allow
