Chapter 4: Web configuration
Object
Request/Reply
Sender IP Filter
Sender IP Address
Sender IP Mask
Target IP Filter
Target IP Address
Target IP Mask
ARP Sender MAC
Match
RARP Target MAC
Match
IP/Ethernet Length
202
Description
Any: No ARP/RARP OP flag is specified. (OP is "don't-care").
ARP: Frame must have ARP/RARP opcode set to ARP.
RARP: Frame must have ARP/RARP opcode set to RARP.
Other: Frame has unknown ARP/RARP Opcode flag.
Specify the available ARP/RARP opcode (OP) flag for this ACE.
Any: No ARP/RARP OP flag is specified. (OP is "don't-care").
Request: Frame must have the ARP Request or RARP Request OP flag set.
Reply: Frame must have ARP Reply or RARP Reply OP flag.
Specify the sender IP filter for this ACE.
Any: No sender IP filter is specified. (Sender IP filter is "don't-care").
Host: Sender IP filter is set to Host. Specify the sender IP address in the SIP
Address field that appears.
Network: Sender IP filter is set to Network. Specify the sender IP address
and sender IP mask in the SIP Address and SIP Mask fields that appear.
When or
Host Network
specific sender IP address in dotted decimal notation.
When is selected for the sender IP filter, you can enter a specific
Network
sender IP mask in dotted decimal notation.
Specify the target IP filter for this specific ACE.
Any: No target IP filter is specified. (Target IP filter is "don't-care").
Host: Target IP filter is set to Host. Specify the target IP address in the
Target IP Address field that appears.
Network: Target IP filter is set to Network. Specify the target IP address and
target IP mask in the Target IP Address and Target IP Mask fields that
appear.
When or
Host Network
specific target IP address in dotted decimal notation.
When is selected for the target IP filter, you can enter a specific
Network
target IP mask in dotted decimal notation.
Specify whether frames can hit the action according to their sender hardware
address field (SHA) settings.
0: ARP frames where SHA is not equal to the SMAC address.
1: ARP frames where SHA is equal to the SMAC address.
Any: Any value is allowed ("don't-care").
Specify whether frames can hit the action according to their target hardware
address field (THA) settings.
0: RARP frames where THA is not equal to the SMAC address.
1: RARP frames where THA is equal to the SMAC address.
Any: Any value is allowed ("don't-care").
Specify whether frames can hit the action according to their ARP/RARP
hardware address length (HLN) and protocol address length (PLN) settings.
0: ARP/RARP frames where the HLN is equal to Ethernet (0x06) and the
(PLN) is equal to IPv4 (0x04).
1: ARP/RARP frames where the HLN is equal to Ethernet (0x06) and the
(PLN) is equal to IPv4 (0x04).
Any: Any value is allowed ("don't-care").
is selected for the sender IP filter, you can enter a
is selected for the target IP filter, you can enter a
