Static aggregation
The Aggregation Mode Configuration page is used to configure the aggregation hash
mode and the aggregation group. The aggregation hash mode settings are global,
whereas the aggregation group relate to the current device, as reflected by the page
header.
The page includes the following fields:
Object
Source MAC Address
Destination MAC Address
IP Address
TCP/UDP Port Number
NS3552-8P-2S-V2 User Manual
Description
The Source MAC address can be used to calculate the destination
port for the frame. Select the check box to enable the use of the
Source MAC address, or uncheck it to disable. By default, the Source
MAC Address is enabled.
The Destination MAC Address can be used to calculate the
destination port for the frame. Select the check box to enable the use
of the Destination MAC Address, or uncheck it to disable. By default,
the Destination MAC Address is disabled.
The IP address can be used to calculate the destination port for the
frame. Select the check box to enable the use of the IP Address, or
uncheck it to disable. By default, IP Address is enabled.
The TCP/UDP port number can be used to calculate the destination
port for the frame. Select the check box to enable the use of the
TCP/UDP Port Number, or uncheck it to disable. By default, the
TCP/UDP Port Number is enabled.
