Chapter 4: Web configuration
LACP system status
The LACP System Status page provides a status overview of all LACP instances. This
page displays the current LACP aggregation groups and LACP port status.
The page includes the following fields:
Object
Aggr ID
Partner System ID
Partner Key
Partner Priority
Last changed
Local Ports
Buttons
• Click to to refresh the page immediately.
Refresh
• Select the
Auto-refresh
seconds.
LACP port status
The LACP Status page provides a LACP status overview of all ports. This page
displays the current LACP aggregation groups and LACP port status.
104
Description
The Aggregation ID associated with this aggregation instance.
For LLAG the ID is shown as 'isid:aggr-id' and for GLAGs as 'aggr-id'
The system ID (MAC address) of the aggregation partner.
The key that the partner has assigned to this aggregation ID.
The priority of the aggregation partner.
The time since this aggregation changed.
Shows which ports are a part of this aggregation for this switch.
check box to automatically refresh the page every three
