Chapter 4: Web configuration
Dynamic IP source guard table
Entries in the Dynamic IP Source Guard Table are shown on this page. The Dynamic
IP Source Guard Table is sorted first by port, then by VLAN ID, then by IP address, and
then by IP mask.
Navigating the dynamic IP source guard table
Each page shows up to 99 entries from the Dynamic IP source guard table, selected
through the "entries per page" input field (default is 20). When first visited, the web
page will show the first 20 entries from the beginning of the table. The first entry
displayed will be the one with the lowest VLAN ID and the lowest MAC address found
in the table.
The port address,
Start from
select the starting point in the table. Clicking the
table starting from that or the closest next Dynamic IP source guard table match.
In addition, the two input fields will, after clicking the
of the first displayed entry, allowing for continuous refresh with the same start address.
The will use the last entry of the currently displayed VLAN/IP address pairs as a
>>
basis for the next lookup. When the end is reached the text "no more entries" is shown
in the displayed table. Use the
The page includes the following fields:
Object
Port
VLAN ID
MAC Address
IP Address
Buttons
• Click
Auto-refresh
every three seconds.
• Click to refresh the displayed table starting from the
Refresh
input fields.
VLAN
264
Address, and
IP
button to start over.
I<<
Description
The port number for which the status applies. Click the port number to see
the status for this particular port.
The VLAN ID of the entry.
The MAC address of the entry.
The IP address of the entry.
to refresh the page automatically. Automatic refresh occurs
input fields allow the user to
VLAN
button updates the displayed
Refresh
button, assume the value
Refresh
MAC address
and
