Chapter 4: Web configuration
The page includes the following fields:
Object
Port
Ingress
Translate
Classify
Egress
Buttons
• Click to save changes.
Save
• Click to undo any changes made locally and revert to previously saved
Reset
values.
DSCP-based QoS
The QoS DSCP-Based QoS Ingress Classification page permits configuration of the
basic QoS DSCP-based QoS ingress classification settings for all switches.
182
Description
The Port column shows the list of ports for which DSCP ingress and egress
settings can be configured.
Change ingress translation and classification settings for individual ports.
There are two configuration parameters available in Ingress:
Translate
Classify
Select the check box to enable the Ingress translation.
Translate
Selections are as follows:
Disable: No Ingress DSCP Classification.
DSCP=0: Classify if incoming (or translated if enabled) DSCP is 0.
Selected: Classify only the selected DSCP for which classification is
enabled as specified in the DSCP Translation window for the specific DSCP.
All: Classify all DSCP.
Selections for Rewrite are as follows:
Disable: No egress rewrite.
Enable: Rewrite enabled without remapping.
Unaware: DSCP from the analyzer is remapped and the frame is
Remap DP
remarked with the remapped DSCP value. The remapped DSCP value is
always taken from the 'DSCP Translation->Egress Remap DP0' table.
Aware: DSCP from the analyzer is remapped and the frame is
Remap DP
remarked with the remapped DSCP value. Depending on the DP level of the
frame, the remapped DSCP value is either taken from the 'DSCP
Translation->Egress Remap DP0' table or from the 'DSCP Translation-
>Egress Remap DP1' table.
