Chapter 6: Command line mode
QoS QCL Refresh
Description:
Resolve QCE conflict status. Same H/W resource is shared by multiple
applications and it may not be available even before MAX QCE entry. So user can
release the resource in use by other applications and use this command to acquire
the resource.
Syntax:
QoS QCL refresh
Parameters:
combined|static|voice_vlan|conflicts: combined
status
: Shows the static user configured status
static
voice_vlan
: Shows all conflict status
conflicts
(default : Shows the combined status)
Default Setting:
disable
Example:
Enable multicast storm control in 2fps
NS3552-8P-2S-V2:/>
QoS Storm multicast enable 2

Mirror Command

Mirror Configuration
Description:
Show mirror configuration.
Syntax:
Mirror Configuration [<port_list>]
Parameters:
<port_list>: Port list or 'all', default: All ports
Example:
Show mirror configuration.
NS3552-8P-2S-V2:/>
mirror configuration
Mirror Port
Description:
Set or show the mirror port.
Syntax:
Mirror Port [<port>|disable]
Parameters:
<port>|disable: Mirror port or 'disable', default: Show port
Default Setting:
disable
Example:
Set port 2 for the mirror port.
446
: Shows the status by Voice VLAN
: Shows the combined
