7.6.6

Dry Contact Setting

Path: → Dry Contact Setting
Input Dry
Contact No.
Input Dry Contact 1
Input Dry Contact 2
Input Dry Contact 3
Input Dry Contact 4
Input Dry Contact 5
Input Dry Contact 6
Output Dry
Contact No.
Output Dry Contact 1
Output Dry Contact 2
Output Dry Contact 3
Output Dry Contact 4
Output Dry Contact 5
Output Dry Contact 6
Event Selection
1. None
2. Generator Status
3. Battery Ground Fail
4. External Battery Breaker
Detection
5. Charge Off
6. Active Standby
7. Battery Abnormal Shutdown
8. Input Transformer OTW
9. Output Transformer OTW
10. Battery Fuse Open
11. Force Sync External Source
12. Input Current Limit Stage Setting
13. Major Battery Abnormal Alarm
14. Minor Battery Abnormal Alarm
Event Selection
1. None
2. Load On Inverter
3. Load On Bypass
4. Load On Battery
5. Battery Low
6. Battery Input Abnormal
7. Battery Test Fail
8. Internal Comm. Fail
9. External Parallel Comm. Fail (only
applicable to parallel application)
10. Output Overload
11. EPO Activated
145
Type
Set up NO
(normally open)
or NC (normally
closed) for each
input dry contact.
Type
Set up NO
(normally open)
or NC (normally
closed) for each
output dry
contact.
