SDM-300A Satellite Modem
3.2

Menu System

To access and execute all functions, refer to Figure 3-4 through Figure 3-22. Use the
Main menu in Figure 3-3 as a quick reference for accessing the modem functions. For
further configuration details, refer to Section 3.2.
Note: Refer to Appendix A for the default settings for IDR, IBS, D&I, and ASYNC
modes.
When the modem power is applied, the base level of the menu system displays the
sign-on message:
•
•
The main level of the menu system is Function Select. To access this level from the
sign-on message, press the [←] or [→] keys. From the Function Select menu; select one
of the functional categories:
•
•
•
•
•
•
Press [←] or [→] to move from one selection to another. When line 2 displays the desired
function, select that level by pressing [ENTER]. After entering the appropriate functional
level, press [←] or [→] to move to the desired function.
To view or change the modem's configuration, enter the Configuration level from the
Function Select menu. Once in the Configuration menu, press [←] or [→] to scroll
through the Configuration menu selection:
•
•
•
•
•
•
•
Press [ENTER] to select the desired Configuration menu option. To view the options for
the selected configuration parameters, press [←] or [→]. To change a configuration
parameter, press [ENTER] to begin the change process.
Rev. 4
Line 1 of the sign-on message is the modem model number and type.
Line 2 is the version number of the firmware.
Configuration
Monitor
Faults/Alarms
Stored Faults/Alarms
Remote AUPC (ASYNC mode only)
Utility
Modulator
Demodulator
Interface
Local AUPC (ASYNC Mode or Local Modem AUPC only)
MUX (Optional)
Save
Recall
Operation
3–5
