SDM-300A Satellite Modem
RX BPSK ORDERING
DEMOD SPECTRUM
RX-RS INTERLEAVE
RX IESS-310 MODE
RX SYMBOL RATE
.
.
Rev. 4
Receive BPSK bit ordering selection. Select STANDARD or NON-
STANDARD.
Press[←], [→], [↑], or [↓] to move the flashing cursor. Press [ENTER]
to execute the change.
Programmable vector rotation. Select NORMAL or INVERT for
spectrum reversal of the I and Q baseband channels.
Press[←], [→], [↑], or [↓] to move the flashing cursor. Press [ENTER]
to execute the change.
Selection of 4, 8, or 16 deep.
Press[←], [→], [↑], or [↓] to move the flashing cursor. Press [ENTER]
to execute the change.
Selection of 8PSK 2/3 with Reed-Solomon.
Press[←], [→], [↑], or [↓] to move the flashing cursor. Press [ENTER]
to execute the change.
Status only.
Selects RX Symbol Rate within 4.8 to 2500 ksps.
Operation
3–55
