Comtech EF Data SDM-300A Installation And Operation Manual page 305

Remote Control Operation
MODEM Command:
Faults Response:
Status
(Summary)
Modulator Command:
Status Response:
Demodulato Command:
r Status Response:
Interface Command:
Transmit Response:
Side Status
Interface Command:
Receive Response:
Side Status
B–30
<add/MFS_'cr'
>add/MFS_'cr'
DMD_xxx'cr'
MOD_xxx'cr'
TX_xxx'cr'
IRX_xxx'cr'
CEQ_xxx'cr'
BWAL_xxx'cr''lf']
<add/MS_'cr'
>add/MS_'cr'
RF_xxx'cr'
MOD_xxx'cr'
SYN_xxx'cr'
DCS_xxx'cr'
ICH_xxx'cr'
QCH_xxx'cr'
AGC_xxx'cr'
SCT_xxx'cr'
EXT_xxx'cr'
CONF_xxx'cr'
SFLT_xx'cr''lf']
<add/DS_'cr'
>add/DS_'cr'
MOD_xxx'cr'
CD_xxx'cr'
SYN_xxx'cr'
ICH_xxx'cr'
QCH_xxx'cr'
BERT_xxx'cr'
CONF_xxx'cr'
SFLT_xx'cr''lf']
<add/ITXS_'cr'
>add/ITXS_'cr'
DRP_xxx'cr'
TXD_xxx'cr'
PLL_xxx'cr'
CLK_xxx'cr'
TAC1_xxx'cr'
TAC2_xxx'cr'
CONF_xxx'cr'
SFLT_xx'cr''lf']
<add/IRXS_'cr'
>add/IRXS_'cr'
UNFL_xxx'cr'
OVFL_xxx'cr'
RXD_xxx'cr'
FBER_xxx'cr'
BWA_xxx'cr'
CLK_xxx'cr'
PLL_xxx'cr'
DMUX_xxx'cr'
2047_xxx'cr'
BUFF_xxx'cr'
INS_xxx'cr'
RAC1_xxx'cr'
RAC2_xxx'cr'
CONF_xxx'cr'
SFLT_xx'cr''lf']
Demodulator (FLT/OK)
Modulator (FLT/OK)
Interface Transmit Side (FLT/OK)
Interface Receive Side (FLT/OK)
Common Equipment (FLT/OK)
Backward Alarms (FLT/OK)
RF Output (ON/OFF) actual status not config
Module (OK/FLT)
IF Synthesizer (OK/FLT)
Data Clock Synthesizer (OK/FLT)
I Channel (OK/FLT)
Q Channel (OK/FLT)
AGC Level (OK/FLT)
Modem Reference PLL Lock (OK/FLT)
Modem Reference Activity (OK/FLT)
Configuration (OK/FLT)
Number of stored faults logged (0 to 10)
Demod Module (OK/FLT)
Carrier Detect (OK/FLT)
IF Synthesizer Lock (OK/FLT)
I Channel (OK/FLT)
Q Channel (OK/FLT)
BER Threshold (OK/FLT)
Configuration (OK/FLT)
Number of stored faults logged (0 to 10)
D&I Drop (OK/FLT)
Transmit Data/AIS (OK/FLT)
Transmit Synthesizer PLL Lock (OK/FLT)
Selected Transmit Clock Activity (OK/FLT)
Transmit Audio Clip Channel #1 (OK/FLT)
Transmit Audio Clip Channel #2 (OK/FLT)
Configuration (OK/FLT)
Number of Stored Faults Logged (0 to 10)
Buffer Underflow (OK/FLT)
Buffer Overflow (OK/FLT)
Receive Data Loss/AIS (OK/FLT)
Frame BER (OK/FLT)
Receive Backward Alarm (OK/FLT)
Selected Buffer Clock Activity (OK/FLT)
Buffer Clock PLL Lock (OK/FLT)
Demux Lock (OK/FLT)
2047 Pattern Lock Detect (OK/FLT)
Buffer Full (OK/FLT)
D&I Insert (OK/FLT)
Receive Audio Clip Channel #1 (OK/FLT)
Receive Audio Clip Channel #2 (OK/FLT)
Configuration (OK/FLT)
Number of Stored Faults Logged (0 to 10)
SDM-300A Satellite Modem
Rev. 4
