Remote Control Operation
Modulator/
Command:
Coder
Response:
Config.
Program
Status
B–22
<add/MCP_'cr'
>add/MCP_'cr'
SMT_xxxxxxx'cr'
ITOT_xxxxx'cr'
MOM_xxxxxxx'cr'
MT_xxxxx'cr'
MET_xxx'cr'
TCEN_1_xxxx'cr'
(Note 6)
TCDR_1_xxxx.x'cr'
(Note 7)
TCEN_2_xxx'cr'
(Note 6)
TCEN_3_xxxx'cr'
(Note 6)
TCDR_3_xxxx.x'cr'
(Note 8)
TCCP_3_yyy'cr'
(Note 8)
TCDP_3_yyy'cr'
(Note 8)
TCEN_4_xxxx'cr'
(Note 6)
TCDR_4_xxxx.x'cr'
(Note 9)
TCCP_4_yyy'cr'
(Note 9)
TCDP_4_yyy'cr'
(Note 9)
MF_nnn.nnnnnn'cr'
MR_nnnn_mmmm.mmm'cr'
MPO_snn.n'cr'
LPC_xxx'cr'
(Note 10)
MOP_snn.n'cr'
(Note 4)
SE_xxx'cr'
DENC_xxx'cr'
ILT_xxx'cr'
ERF_nnnnn.n'cr'
TC_xxxx'cr'
TCP_xxxx'cr'
BBL_xxx'cr'
ILB_xxx'cr'
ILT_xxx'cr'
ICFT_xxxx'cr'
ISP_xxxxxx'cr'
ISP_xxx'cr'
TDF_xxxx'cr'
ISCL_TX1_nnn'cr'
ISCL_TX2_nnn'cr'
TDP_xxxx'cr'
DDF_xxxxxx'cr'
(Note 1)
BDCA_dd;cc_dd;cc...'cr'
(Note 1)
MRC_xxx'cr'
MSR_xxx'cr'
RSEN_xxx'cr'
BW_TX1_nnn'cr'
(Note 2)
BW_TX2_nnn'cr'
(Note 2)
BW_TX3_nnn'cr'
(Note 2)
BW_TX4_nnn'cr'
(Note 2)
TXDR_xxxxxx'cr'
TOBR_nnnnn'cr'
(Note 3)
TCCL_n'cr'
(Note 3)
TCSB_n'cr'
(Note 3)
TOCP_xxxx'cr'
(Note 3)
TCT_xxxxx'cr'
(Note 3)
NOMP_snn.n'cr'
(Note 10)
MINP_snn.n'cr'
(Note 10)
MAXP_snn.n'cr'
(Note 10)
LCL_xxxx'cr'
(Note 10)
RCL_xxxx'cr'
(Note 10)
CTSD_xx'cr'
RTSM_xxx'cr'
TDA_xxx'cr'
COM_xxxxxx'cr'
TET_xxxxx'cr'
(Note 2)
MTDR_1_yyyyyy'cr'
(Note 5)
MTIT_1_yyyyy'cr'
(Note 5)
MTCP_1_yyy'cr'
(Note 5)
System Modem Type
Interface Transmit Overhead Type
Modem Operation Mode
Modulator Type
Modulator Encoder Type
Flex Mux TX Channel #1 Enable
Flex Mux TX Channel #1 Data Rate
Flex Mux TX Channel #2 Enable
Flex Mux TX Channel #3 Enable
Flex Mux TX Channel #3 Data Rate
Flex Mux TX Channel #3 Clock Phase
Flex Mux TX Channel #3 Data Phase
Flex Mux TX Channel #4 Enable
Flex Mux TX Channel #4 Data Rate
Flex Mux TX Channel #4 Clock Phase
Flex Mux TX Channel #4 Data Phase
Modulator Frequency
Modulator Rate
Modulator Power Offset
AUPC Local Power Enable
Modulator Output Power
Scrambler Enable
Differential Encoder
Interface Loop Timing
External Reference Frequency
Transmit Clock (Source)
Transmit Clock Phase
Baseband Loopback
Interface Loopback
Interface Loop Timing
Interface Coding Format Transmit
Interface Substitution Pattern (TX 2047)
Interface Substitution Pattern (TX 2047)
Transmit Data Fault
Service Channel Level TX1
Service Channel Level TX2
Transmit Data Phase
Drop Data Format
Bulk Drop Channels Assignment
Modulator Reference Clock
Modulator Spectrum Rotation
Reed-Solomon Encoder
Backward Alarm Enable TX1
Backward Alarm Enable TX2
Backward Alarm Enable TX3
Backward Alarm Enable TX4
TX Driver Type
ASYNC Transmit Overhead Baud Rate
ASYNC Transmit Channel Character Length
ASYNC Transmit Channel Stop Bits
ASYNC Transmit Overhead Channel Parity
ASYNC Transmit Communications Type
AUPC Nominal Power Value
AUPC Minimum Power Value
AUPC Maximum Power Value
AUPC Local Carrier Loss
AUPC Remote Carrier Loss
CTS Delay Time
RTS TX-IF Control Mode
Transmit BPSK Data Ordering
Carrier Only Mode
IDR Transmit ESC Type
Mux Tributary #1 Data Rate & Enable
Mux Tributary #1 Interface Type
Mux Tributary #1 Clock Phase
SDM-300A Satellite Modem
Rev. 4
