SDM-300A Satellite Modem
REV EMULATION
MODEM OPTIONS
CARD #1 TYPE
CARD #2 TYPE
CARD #3 TYPE
CARD #1 OPTIONS
CARD #2 OPTIONS
CARD #3 OPTIONS
Rev. 4
Programs an emulation mode of a previous functional revision. This allows the
user to select the CURRENT VERSION or FUNCTIONAL X.
Note: The number displayed in the CURRENT VERSION position increases
with each software version change.
Upon entry, the CURRENT VERSION is displayed. Press [↑] or [↓] to select
the FUNCTIONAL version. Press [ENTER] to execute the change.
Notes:
1.
Programming a current version (default) allows all features and
options (if installed) to operate normally.
2.
Programming a FUNCTIONAL version (X) eliminates any
changes that affect the later version. Only functional changes are
affected by the revision emulation feature.
3.
A correction change (e.g., VER 3.1.2) remains fixed in accordance
with the latest version. Since the revision emulation default is the
current version, program the functional version at the start of each
operation.
4.
The revision emulation feature does not affect some interface
changes for the direct operation of the modem (Configuration
save/recall, test mode screen in the Utility/System, all factory
setup modes, etc.).
(Status Only.)
Displays the installed modem options.
If the option is installed, a "+" symbol is displayed. To view the available
options press [ENTER]. Observe for the flashing cursor. Press the [←] [→]
arrows to move from one symbol to the next. The first line will display the
option. The second line will display the status:
•
A "+" symbol indicates the option is installed.
•
A "-" symbol indicates the option is FAST accessible.
•
A "0" symbol indicates the option is a factory upgrade.
•
An "x" symbol indicates the option is field insertable.
(Status Only.)
Displays installed overhead card.
(Status Only.)
Displays installed Reed-Solomon card.
(Status Only.)
Displays installed Reed-Solomon card.
(Status Only.)
Displays installed overhead options.
(Status Only.)
Displays installed Reed-Solomon options.
(Status Only.)
Displays installed Reed-Solomon options.
Operation
3–69
