Comtech EF Data SDM-300A Installation And Operation Manual page 280

SDM-300A Satellite Modem
Scrambler Command:
Enable Response:
Status:
Response:
Differential Command:
Encoder Response:
Enable
Status:
Response:
Modulator Command:
Type Response:
Status:
Response:
Modulator Command:
Encoder Response:
Type
Status:
Response:
Modem Command:
Reference Response:
Clock
Status:
Response:
Modulator Command:
Spectrum Response:
Rotation
Status:
Response:
Reed- Command:
Solomon Response:
Encoder
Enable Status:
Response:
Transmit Command:
BPSK Data Response:
Ordering
Status:
Response:
Carrier Only Command:
Mode Response:
Status:
Response:
TX Reed- Command:
Solomon Response:
Interleave
Value Status:
Response:
Rev. 4
<add/SE_xxx'cr'
>add/SE_xxx'cr''lf']
<add/SE_'cr'
>add/SE_xxx'cr''lf']
<add/DENC_xxx'cr'
>add/DENC_xxx'cr''lf']
<add/DENC_'cr'
>add/DENC_xxx'cr''lf']
<add/MT_xxxx'cr'
>add/MT_xxxx'cr''lf']
<add/MT_xxxx'cr'
>add/MT_xxxx'cr''lf']
<add/MET_xxx'cr'
>add/MET_xxx'cr''lf']
<add/MET_xxx'cr'
>add/MET_xxx'cr''lf']
<add/MRC_xxxxx'cr'
>add/MRC_xxxxx'cr''lf']
<add/MRC_'cr'
>add/MRC_xxxxx'cr''lf']
<add/MSR_xxx'cr'
>add/MSR_xxx'cr''lf']
<add/MSR_'cr'
>add/MSR_xxx'cr''lf']
<add/RSEN_xxx'cr'
>add/RSEN_xxx'cr''lf']
<add/RSEN_'cr'
>add/RSEN_xxx'cr''lf']
<add/TDA_xxx'cr'
>add/TDA_xxx'cr''lf']
<add/TDA_xxx'cr'
>add/TDA_xxx'cr''lf']
<add/COM_xxxxxx'cr'
>add/COM_xxxxxx'cr''lf']
<add/COM_xxxxxx'cr'
>add/COM_xxxxxx'cr''lf']
<add/TRSI_xx'cr'
>add/TRSI_xx'cr''lf']
<add/TRSI_'cr'
>add/TRSI_xx'cr''lf']
Where: xxx = ON or OFF.
Where: xxx = ON or OFF.
Where: xxxx = INTL (INTELSAT OPEN NETWORK), EFD
(EF DATA CLOSED NETWORK), CSC (COMSTREAM
CLOSED NETWORK), FDC (FAIRCHILD CLOSED
NETWORK), SDM51 (SDM51 COMPATIBLE).
Where: xxx = VIT (K-7 VITERBI ENCODER), SEQ
(SEQUENTIAL ENCODER).
Where: xxxxx = INT (INTERNAL), EXT1 (EXTERNAL 1
MHz), EXT5 (EXTERNAL 5 MHz), EXT10 (EXTERNAL 10
MHz), EXT20 (EXTERNAL 20 MHz), OUT10 (OUTPUT 10
MHz).
Where: xxx = NRM (normal spectrum), INV (inverted
spectrum).
Where: xxx = ON or OFF.
Where: xxx = NRM (STANDARD), INV (NON-STANDARD).
Where: xxxxxx = OFF (NORMAL-MODULATED), DUAL
(DUAL-CW), OFFSET (OFFSET-CW), CENTER (CENTER-
CW).
Where: xx = 4, 8, or 16.
Remote Control Operation
B–5
