SDM-300A Satellite Modem
Rev. 4
TCEN_2_xxx'cr'
(Note 8)
TCEN_3_xxxx'cr'
(Note 8)
TCDR_3_xxxx.x'cr'
(Note 10)
TCCP_3_yyy'cr'
(Note 10)
TCDP_3_yyy'cr'
(Note 10)
TCEN_4_xxxx'cr'
(Note 8)
TCDR_4_xxxx.x'cr'
(Note 11)
TCCP_4_yyy'cr'
(Note 11)
TCDP_4_yyy'cr'
(Note 11)
RCEN_1_xxxx'cr'
(Note 8)
RCDR_1_xxxx.x'cr'
(Note 12)
RCEN_2_xxx'cr'
(Note 8)
RCEN_3_xxxx'cr'
(Note 8)
RCDR_3_xxxx.x'cr'
(Note 13)
RCCP_3_yyy'cr'
(Note 13)
RCDP_3_yyy'cr'
(Note 13)
RCEN_4_xxxx'cr'
(Note 8)
RCDR_4_xxxx.x'cr'
(Note 14)
RCCP_4_yyy'cr'
(Note 14)
RCDP_4_yyy'cr''lf'
]
(Note 14)
Flex Mux TX Channel #2 Enable
Flex Mux TX Channel #3 Enable
Flex Mux TX Channel #3 Data Rate
Flex Mux TX Channel #3 Clock Phase
Flex Mux TX Channel #3 Data Phase
Flex Mux TX Channel #4 Enable
Flex Mux TX Channel #4 Data Rate
Flex Mux TX Channel #4 Clock Phase
Flex Mux TX Channel #4 Data Phase
Flex Mux RX Channel #1 Enable
Flex Mux RX Channel #1 Data Rate
Flex Mux RX Channel #2 Enable
Flex Mux RX Channel #3 Enable
Flex Mux RX Channel #3 Data Rate
Flex Mux RX Channel #3 Clock Phase
Flex Mux RX Channel #3 Data Phase
Flex Mux RX Channel #4 Enable
Flex Mux RX Channel #4 Data Rate
Flex Mux RX Channel #4 Clock Phase
Flex Mux RX Channel #4 Data Phase
The Interface configuration status command causes a block of
data to be returned by the addressed MODEM. The block
reflects the current configuration of the interface. Additional
configuration status of new options and features will always be
appended to the end.
Notes:
1. Data is only returned for TX D&I Overhead.
2. Data is only returned for RX D&I Overhead.
3. Data is only returned for TX IDR Overhead.
4. Data is only returned for RX IDR Overhead.
5. Data is only returned for TX ASYNC Overhead.
6. Data is only returned for RX ASYNC Overhead.
7.
Data is only returned if MUX PCB (Card Slot #1) is
installed.
8. Data is only returned if FLEX MUX PCB (Card Slot #1)
is installed.
9. Data not returned if TX Channel #1 is disabled.
10. Data not returned if TX Channel #3 is disabled or set
for AUPC.
11. Data not returned if TX Channel #4 is disabled or set
for AUPC.
12. Data not returned if RX Channel #1 is disabled.
13. Data not returned if RX Channel #3 is disabled or set
for AUPC.
14. Data not returned if RX Channel #4 is disabled or set
for AUPC.
Remote Control Operation
B–29
