Comtech EF Data SDM-300A Installation And Operation Manual page 287

Remote Control Operation
Bulk Insert Command:
Channels Response:
Assignment
Status:
Response:
ASYNC Command:
Transmit Response:
Overhead
Baud Rate Status:
Response:
ASYNC Command:
Receive Response:
Overhead
Baud Rate Status:
Response:
ASYNC Command:
Transmit Response:
Channel
Character Status:
Length Response:
ASYNC Command:
Receive Response:
Channel
Character Status:
Length Response:
ASYNC Command:
Transmit Response:
Channel
Stop Bits Status:
Response:
ASYNC Command:
Receive Response:
Channel
Stop Bits Status:
Response:
B–12
<add/BICA_ii;cc_ii;cc_ii;cc_ii;cc......'cr'
>add/BICA_ii;cc_ii;cc_ii;cc_ii;cc......'cr''lf']
<add/BICA_'cr'
>add/BICA_ii;cc_ii;cc_ii;cc_ii;cc......'cr''lf']
<add/TOBR_nnnnn'cr'
>add/TOBR_nnnnn'cr''lf']
<add/TOBR_'cr'
>add/TOBR_nnnnn'cr''lf']
<add/ROBR_nnnnn'cr'
>add/ROBR_nnnnn'cr''lf']
<add/ROBR_'cr'
>add/ROBR_nnnnn'cr''lf']
<add/TCCL_n'cr'
>add/TCCL_n'cr''lf']
<add/TCCL_'cr'
>add/TCCL_n'cr''lf']
<add/RCCL_n'cr'
>add/RCCL_n'cr''lf']
<add/RCCL_'cr'
>add/RCCL_n'cr''lf']
<add/TCSB_n'cr'
>add/TCSB_n'cr''lf']
<add/TCSB_'cr'
>add/TCSB_n'cr''lf']
<add/RCSB_n'cr'
>add/RCSB_n'cr''lf']
<add/RCSB_'cr'
>add/RCSB_n'cr''lf']
SDM-300A Satellite Modem
Where:
ii = 1 to N (over the satellite insert channel);
where N = (modulator data rate) divided by
(64 kbit/s).
cc = 1 to 24 (terrestrial channel number for T1
data formats).
cc = 1 to 31 (terrestrial time slot number for E1
data formats).
cc = 0 if no insert is desired for the specified
insert channel.
Notes:
1. The status response returns programming
information for 1 to N insert channels.
2. Time slot 16 (cc = 16) may not be
specified when the insert data format is
specified to be E1CAS.
3. This command is not valid when the insert
data format is specified as E1CAS and the
demodulator data rate is set to 1920.0
kbit/s.
Where: nnnnn = 110, 150, 300, 600, 1200, 2400,
4800, 9600, 19200, or 38400.
Note: TX ASYNC Overhead only.
Where: nnnnn = 110, 150, 300, 600, 1200, 2400,
4800, 9600, 19200, or 38400.
Note: RX ASYNC Overhead only.
Where: n = 5, 6, 7, or 8 (characters).
Note: TX ASYNC Overhead only.
Where: n = 5, 6, 7, or 8 (characters).
Note: RX ASYNC Overhead only.
Where: n = 1 or 2 (stop bits).
Note: TX ASYNC Overhead only.
Where: n = 1 or 2 (stop bits).
Note: RX ASYNC Overhead only.
Rev. 4
