Remote Control Operation
B–24
Notes:
1. Data is only returned for TX D&I Overhead (or Flex
Mux D&I).
2. Data is only returned for TX IDR Overhead.
3. Data is only returned for TX ASYNC Overhead
4. Data not returned if Local AUPC is enabled & TX
ASYNC overhead.
5. Data is only returned if MUX PCB (Card Slot #1) is
installed.
6. Data is only returned if FLEX MUX PCB (Card Slot
#1) is installed.
7. Data not returned if Channel #1 is disabled.
8. Data not returned if Channel #3 is disabled or set for
AUPC.
9. Data not returned if Channel #4 is disabled or set for
AUPC.
10 Data is only returned for TX ASYNC Overhead( or
Flex Mux AUPC).
