3.3.6
Configuration Flex Mux
Refer to Figure 3-9.
TX CHAN # 1 MODE
TX CHAN # 1 DR
TX CHAN # 2 MODE
TX CHAN # 3 MODE
TX CHAN # 3 DR
TX CHAN # 3 PHASE
TX CHAN # 4 MODE
TX CHAN # 4 DR
TX # 4 PHASE
3–32
Programs the TX Channel # 1 Mode: D&I Enabled, T1/E1 Enabled, or
Disabled.
Press[←] or [→] to move the flashing cursor, and [↑] or [↓] to increment
or decrement the selected kbit/s. Press [ENTER] to execute the change.
Programs the TX Channel # 1 Drive: 1544 kbit/s or 2048 kbit/s for Bypass.
64 kbit/s for D&I.
Press[←] or [→] to move the flashing cursor, and [↑] or [↓] to increment
or decrement the selected kbit/s. Press [ENTER] to execute the change.
Programs the TX Channel # 2 mode: ADPCM Enabled or Disabled.
Press[←] or [→] to move the flashing cursor, and [↑] or [↓] to increment
or decrement the selected kbit/s. Press [ENTER] to execute the change.
Programs the TX Channel # 3 mode: ASYNC EIA-232, SYNC EIA-232,
ASYNC EIA-422, SYNC EIA-422, AUPC, or Disabled.
Press[←] or [→] to move the flashing cursor, and [↑] or [↓] to increment
or decrement the selected kbit/s. Press [ENTER] to execute the change.
Programs the TX Channel # 3 Drive: SYNC EIA-422, 0.6 to 4000 kbit/s.
Press[←] or [→] to move the flashing cursor, and [↑] or [↓] to increment
or decrement the selected kbit/s. Press [ENTER] to execute the change.
Programs the TX # 3 Phase, Normal or Inverted.
Press[←] or [→] to move the flashing cursor, and [↑] or [↓] to increment
or decrement the selected kbit/s. Press [ENTER] to execute the change.
Programs the TX Channel #4 mode: ASYNC EIA-232, SYNC EIA-232,
ASYNC EIA-485, AUPC, or Diabled.
Press[←] or [→] to move the flashing cursor, and [↑] or [↓] to increment
or decrement the selected kbit/s. Press [ENTER] to execute the change.
Programs the TX Channel # 4 Drive., 0.6 to 64 kbit/s.
Press[←] or [→] to move the flashing cursor, and [↑] or [↓] to increment
or decrement the selected kbit/s. Press [ENTER] to execute the change.
Programs the TX # 4 Phase, Normal or Inverted.
Press[←] or [→] to move the flashing cursor, and [↑] or [↓] to increment
or decrement the selected kbit/s. Press [ENTER] to execute the change.
