Remote Control Operation
B.3

Configuration Commands/Responses

B.3.1

Modulator Configuration Commands

Modulator Command:
Frequency Response:
Status:
Response:
RF Output Command:
(IF Output) Response:
Status:
Response:
Modulator Command:
Rate Preset Response:
Assignment
Status:
Response:
Modulator Command:
Rate Preset Response:
Selection
Status:
Modulator Command:
Rate Response:
Variable
Assignment
& Selection Status:
Set Command:
Modulator Response:
Power
Offset Status:
Response:
Set Command:
Modulator Response:
Output
Power Level Status:
Response:
B–4
<add/MF_nnn.nnnnnn'cr'
>add/MF_nnn.nnnnnn'cr'
RF_OFF'cr''lf']
<add/MF_'cr'
>add/MF_nnn.nnnnnn'cr''lf']
<add/RF_xxx'cr'
>add/RF_xxx'cr''lf']
<add/RF_'cr'
>add/RF_xxx'cr''lf']
<add/AMRx_nnnn_mmmm.mmm'cr'
>add/AMRx_nnnn_mmmm.mmm'cr''l
f']
<add/AMRx_'cr'
>add/AMRx_nnnn_mmmm.mmm'cr''l
f']
<add/SMRx_'cr'
>add/SMRx_'cr'
RF_OFF'cr''lf']
See MR command.
<add/SMRV_nnnn_mmmm.mmm'cr'
>add/SMRV_nnnn_mmmm.mmm'cr'
RF_OFF'cr''lf']
See MR command.
<add/MPO_snn.n'cr'
>add/MPO_snn.n'cr''lf']
<add/MPO_'cr'
>add/MPO_snn.n'cr''lf']
<add/MOP_snn.n'cr'
>add/MOP_snn.n'cr''lf']
<add/MOP_'cr'
>add/MOP_snn.n'cr''lf']
Where: nnn.nnnnnn = Frequency in MHz, 50.000000 to
180.000000 in 1 Hz steps.
Note: When the modulator frequency is programmed, the
RF output is switched off.
Where: xxx = ON or OFF.
Where:
x = A, B, C, D, or V [preset designator].
nnnn = 1/2 (QPSK 1/2), [coder rate], 3/4 (QPSK 3/4), 7/8
(QPSK 7/8), BP12 (BPSK 1/2), 8P23 (8PSK 2/3), OQ12
(OQPSK 1/2), OQ34 (OQPSK 3/4), and
OQ78 (OQPSK 7/8).
mmmm.mmm = Data rate in kHz.
Where: x = A, B, C, D, or V (preset designator).
Note: Setting the modulator rate turns off the RF transmitter.
Where: mmmm.mmm = Data rate in kHz.
nnnn = 1/2 (QPSK 1/2), [coder rate], 3/4 (QPSK 3/4), 7/8
(QPSK 7/8), BP12 (BPSK 1/2), 8P23 (8PSK 2/3), OQ12
(OQPSK 1/2), OQ34 (OQPSK 3/4), and
OQ78 (OQPSK 7/8).
Note: Setting the modulator turns off the RF transmitter.
Where: snn.n = +99.0 to –99.0, in 0.1 dB increments.
Note: The modulator power offset is added to the nominal
power level to adjust the transmit power range.
Where: snn.n = -30.0 to –5.0, in 0.1 steps (nominal range in
dBm).
Notes:
2. The nominal power range is modified relative to the
value specified by the modulator power offset
(MPO_).
2. The MOP_ command will return status only when
local AUPC is enabled.
SDM-300A Satellite Modem
Rev. 4
