Operation
ASYNC RX BAUD
ASYNC TX LENGTH
ASYNC RX LENGTH
ASYNC TX STOP
ASYNC RX STOP
ASYNC TX PARITY
ASYNC RX PARITY
3–24
Programs the ASYNC overhead receive baud rate.
Upon entry, the status of the ASYNC RX baud rate is displayed. Press
[↑] or [↓] key to select one baud rate. Press [ENTER] to execute the
change.
Note: Only available for the RX ASYNC option.
Programs the ASYNC overhead transmit word length for 5, 6, 7, or 8
bits.
Upon entry, the status of the ASYNC TX word length is displayed.
Press [↑] or [↓] to make the selection. Press [ENTER] to execute the
change.
Note: Only available for the TX ASYNC option.
Programs the ASYNC overhead receive word length for 5, 6, 7, or
8 bits.
Upon entry, the status of the ASYNC RX word length is displayed.
Press [↑] or [↓] to make the selection. Press [ENTER] to execute the
change.
Note: Only available for the RX ASYNC option.
Programs the ASYNC overhead transmit stop bits for 1 or 2.
Upon entry, the status of the ASYNC TX stop bits is displayed. Press
[↑] or [↓] to make the selection. Press [ENTER] to execute the change.
Note: Only available for the TX ASYNC option.
Programs the ASYNC overhead receive stop bits for 1 or 2.
Upon entry, the status of the ASYNC RX stop bits make the selection.
Press [ENTER] to execute the change.
Note: Only available for the RX ASYNC option.
Programs the ASYNC overhead transmit parity for Even, Odd, or
None.
Upon entry, the status of the ASYNC TX parity is displayed. Press [↑]
or [↓] to make the selection. Press [ENTER] to execute the change.
Note: Only available for the TX ASYNC option.
Programs the ASYNC overhead receive parity for Even, Odd, or
None.
Upon entry, the status of the ASYNC RX parity is displayed. Press [↑]
or [↓] to make the selection. Press [ENTER] to execute the change.
Note: Only available for the RX ASYNC option.
SDM-300A Satellite Modem
Rev. 4
