SDM-300A Satellite Modem
B.3.6

MUX PCB Configuration Commands (MUX PCB Installed Only)

Mux Command:
Tributary Response:
Data Rate &
Enable Status:
Response:
Mux Command:
Tributary Response:
Interface
Type Status:
Response:
Mux Command:
Tributary Response:
Clock
Phase Status:
Response:
Mux Command:
Tributary Response:
Data Phase
Status:
Response:
Mux Command:
Tributary Response:
Mode
Status:
Response:
Mux Command:
Tributary Response:
Async
Format Status:
Response:
Rev. 4
<add/MTDR_x_yyyyyy'cr'
>add/MTDR_x_yyyyyy'cr''lf']
<add/MTDR_x'cr'
>add/MTDR_x_yyyyyy'cr''lf']
<add/MTIT_x_yyyyy'cr'
>add/MTIT_x_yyyyy'cr''lf']
<add/MTIT_x'cr'
>add/MTIT_x_yyyyy'cr''lf']
<add/MTCP_x_yyy'cr'
>add/MTCP_x_yyy'cr''lf']
<add/MTCP_x'cr'
>add/MTCP_x_yyy'cr''lf']
<add/MTDP_x_yyy'cr'
>add/MTDP_x_yyy'cr''lf']
<add/MTDP_x'cr'
>add/MTDP_x_yyy'cr''lf']
<add/MTMD_x_yyyyy'cr'
>add/MTMD_x_yyyyy'cr''lf']
<add/MTMD_x'cr'
>add/MTMD_x_yyyyy'cr''lf']
<add/MTAF_x_yyy'cr'
>add/MTAF_x_yyy'cr''lf']
<add/MTAF_x'cr'
>add/MTAF_x_yyy'cr''lf']
Remote Control Operation
Where:
x = 1 to 8 (tributary number).
yyyyyy = OFF (disabled), or 0.6 to 4000.0 (kbit/s in
100 bits steps).
Where:
x = 1 to 8 (tributary number).
yyyyy = RS422 or RS232.
Where:
x = 1 to 8 (tributary number).
yyy = NRM (normal clock phasing), INV (inverted
clock phasing).
Where:
x = 1 to 8 (tributary number).
yyy = NRM (normal data phasing), INV (inverted data
phasing).
Where:
x = 1 to 8 (tributary number).
yyyyy = SYNC or ASYNC.
Where:
x = 1 to 8 (tributary number).
yyy = 7E1, 7O1, 7N2, 7E2, 7O2, 8N1, or 8N2.
B–17
