Operation
LOCAL MODEM
AUPC
MODEM SERIAL #
CARD #1 SERIAL #
CARD #2 SERIAL #
CARD #3 SERIAL #
CONFIGURATION
CODE - MODE
CONFIGURATION
CODE - CARD #1
CONFIGURATION
CODE - CARD #2
CONFIGURATION
CODE - CARD #3
3–70
Configures the modem for the self-monitoring Local Modem AUPC mode and
for local TX power control (self-monitoring) due to severe rain fade.
Notes:
1.
The self-monitoring Local Modem AUPC mode is not used when the
ASYNC/AUPC is selected as the Modem Type.
2.
Used for local control (self-monitoring) due to severe rain fade.
Refer to Appendix A for more information.
(Status Only).
Displays the modem serial number.
(Status Only.)
Displays the first daughter card serial number.
(Status Only.)
Displays the second daughter card serial number.
(Status Only.)
Displays the second daughter card serial number.
EFData–supplied code.
On entry, the current configuration code is displayed with the flashing cursor
on the first character. Press [←] or [→] to move the flashing cursor. Press [↑]
or [↓] to increment or decrement the digit at the flashing cursor. Press
[ENTER] to execute the change.
Entering this code enables the corresponding modem option. To purchase an
option, contact an EFData marketing representative for more information.
Provides the means to enter modem-specific code necessary to access certain
options. Refer to Appendix A for more information.
Note: Displays only when daughter card is installed.
Provides the means to enter modem-specific code necessary to access certain
options. Refer to Appendix A for more information.
Note: Displays only when second daughter card is installed.
Provides the means to enter modem-specific code necessary to access certain
options. Refer to Appendix A for more information.
Note: Displays only when second daughter card is installed.
SDM-300A Satellite Modem
Rev. 4
