SDM-300A Satellite Modem
Bulk Consol.
Status
(continued)
Parameter
Number
(Note 9)
123
(Note 9)
124
(Note 9)
125
(Note 7)
126
(Note 10)
127
(Note 10)
128
(Note 10)
129
(Note 7)
130
(Note 11)
131
(Note 7)
132
(Note 7)
133
(Note 12)
134
(Note 12)
135
(Note 12)
136
(Note 7)
137
(Note 13)
138
(Note 13)
139
(Note 13)
140
Rev. 4
Parameter Name
(Command Reference)
TX Flex Mux Channel #3 Data Rate
(ref. "TCDR_3" command).
TX Flex Mux Channel #3 Clock Phase
(ref. "TCCP_3" command).
TX Flex Mux Channel #3 Data Phase
(ref. "TCDP_3" command).
TX Flex Mux Channel #4 Enable
(ref. "TCEN_4" command).
TX Flex Mux Channel #4 Data Rate
(ref. "TCDR_4" command).
TX Flex Mux Channel #4 Clock Phase
(ref. "TCCP_4" command).
TX Flex Mux Channel #4 Data Phase
(ref. "TCDP_4" command).
RX Flex Mux Channel #1 Enable
(ref. "RCEN_1" command).
RX Flex Mux Channel #1 Data Rate
(ref. "RCDR_1" command).
RX Flex Mux Channel #2 Enable
(ref. "RCEN_2" command).
RX Flex Mux Channel #3 Enable
(ref. "RCEN_3" command).
RX Flex Mux Channel #3 Data Rate
(ref. "RCDR_3" command).
RX Flex Mux Channel #3 Clock
Phase
(ref. "RCCP_3" command).
RX Flex Mux Channel #3 Data Phase
(ref. "RCDP_3" command).
RX Flex Mux Channel #4 Enable
(ref. "RCEN_4" command).
RX Flex Mux Channel #4 Data Rate
(ref. "RCDR_4" command).
RX Flex Mux Channel #4 Clock
Phase
(ref. "RCCP_4" command).
RX Flex Mux Channel #4 Data Phase
(ref. "RCDP_4" command).
Remote Control Operation
Description
p123 = nnnn.n, where 'nnnn.n' is the data rate in Kbps.
p124 = n, where 'n' is '0' (Normal) or '1' (Invert).
p125 = n, where 'n' is '0' (Normal) or '1' (Invert).
p126 = n, where 'n' is '0' (Disabled), '1' (Sync RS232), '2'
(Async RS232), '3' (Async RS485), or '4' (AUPC
operation).
p127 = nnnn.n, where 'nnnn.n' is the data rate in Kbps.
p128 = n, where 'n' is '0' (Normal) or '1' (Invert).
p129 = n, where 'n' is '0' (Normal) or '1' (Invert).
p130 = n, where 'n' is '0' (Disabled), '1' (D&I), or '2' (T1/E1
operation).
p131 = nnnn.n, where 'nnnn.n' is the data rate in Kbps.
p132 = n, where 'n' is '0' (Disabled), '1' (Enabled).
p133 = n, where 'n' is '0' (Disabled), '1' (Sync RS422), '2'
(Async RS422), '3' (Sync RS232), '4' (Async RS232), or
'5' (AUPC operation).
p134 = nnnn.n, where 'nnnn.n' is the data rate in Kbps.
p135 = n, where 'n' is '0' (Normal) or '1' (Invert).
p136 = n, where 'n' is '0' (Normal) or '1' (Invert).
p137 = n, where 'n' is '0' (Disabled), '1' (Sync RS232), '2'
(Async RS232), '3' (Async RS485), or '4' (AUPC
operation).
p138 = nnnn.n, where 'nnnn.n' is the data rate in Kbps.
p139 = n, where 'n' is '0' (Normal) or '1' (Invert).
p140 = n, where 'n' is '0' (Normal) or '1' (Invert).
B–45
