Comtech EF Data SDM-300A Installation And Operation Manual page 335

SDM-300A Satellite Modem
Modulation
Type
QPSK 1/2
QPSK 1/2
QPSK 1/2
QPSK 1/2
QPSK 1/2
QPSK 1/2
QPSK 3/4
QPSK 3/4
QPSK 7/8
QPSK 7/8
BPSK 1/2
BPSK 1/2
8PSK 2/3
8PSK 2/3
QPSK 1/2
QPSK 1/2
8PSK 2/3
8PSK 2/3
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
8PSK 2/3
8PSK 2/3
8PSK 2/3
8PSK 2/3
BPSK 1/1
QPSK 1/1
OQPSK 1/1
Rev. 4
Table C-4. Modulator Digital Data Rate (Continued)
Encoding Type
IBS
IBS and Reed-Solomon
D&I
D&I and Reed-Solomon
ASYNC
ASYNC and Reed-Solomon
ASYNC
ASYNC and Reed-Solomon
ASYNC
ASYNC and Reed-Solomon
ASYNC
ASYNC and Reed-Solomon
IBS
IBS and Reed-Solomon
D&I
D&I and Reed-Solomon
ASYNC
ASYNC and Reed-Solomon
IDR, T1
IDR, T1, and Reed-Solomon
IDR, E1
IDR, E1, and Reed-Solomon
IDR, T1
IDR, T1, and Reed-Solomon
IDR, E1
IDR, E1, and Reed-Solomon
None
None
None
Data Rate Range
64 kbit/s 2048 kbit/s
64 kbit/s 2048 kbit/s
64 kbit/s 1920 kbit/s
64 kbit/s 1920 kbit/s
4.8 kbit/s 2048 kbit/s
4.8 kbit/s 2048 kbit/s
7.2 kbit/s 2048 kbit/s
7.2 kbit/s 2048 kbit/s
8.4 kbit/s 2048 kbit/s
8.4 kbit/s 2048 kbit/s
2.4 kbit/s 1024 kbit/s
2.4 kbit/s 1024 kbit/s
512 kbit/s 2048 kbit/s
512 kbit/s 2048 kbit/s
64 kbit/s 1920 kbit/s
64 kbit/s 1920 kbit/s
512 kbit/s 2048 kbit/s
512 kbit/s 2048 kbit/s
1544 kbit/s Fixed Rate
1544 kbit/s
2048 kbit/s
2048 kbit/s
1544 kbits Fixed Rate
1544 kbits
2048 kbits
2048 kbits
4.8 kbit/s 2.5 Mbit/s
9.6 kbit/s 5.0 Mbit/s
9.6 kbit/s 5.0 Mbit/s
Specifications
C–5
