Comtech EF Data SDM-300A Installation And Operation Manual page 329

Remote Control Operation
RX Channel Command:
#1 Enable Response:
Status:
Response:
RX Channel Command:
#2 Enable Response:
Status:
Response:
RX Channel Command:
#3 Enable Response:
Status:
Response:
RX Channel Command:
#3 Data Response:
Rate
Status:
Response:
RX Channel Command:
#4 Enable Response:
Status:
Response:
RX Channel Command:
#4 Data Response:
Rate
Status:
Response:
RX Channel Command:
Clock Response:
Phase
(Channels Status:
#3 and #4) Response:
RX Channel Command:
Data Phase Response:
(Channels
#3 and #4) Status:
Response:
RX Channel Command:
Select for Response:
2047 BER
Monitor Status:
Response:
B–54
<add/RCEN_1_xxx'cr'
>add/RCEN_1_xxx'cr''lf']
<add/RCEN_1'cr'
>add/RCEN_1_xxx'cr''lf']
<add/RCEN_2_xxx'cr'
>add/RCEN_2_xxx'cr''lf']
<add/RCEN_2'cr'
>add/RCEN_2_xxx'cr''lf']
<add/RCEN_3_xxxxxxxxxxx'cr'
>add/RCEN_3_xxxxxxxxxxx'cr''lf']
<add/RCEN_3'cr'
>add/RCEN_3_xxxxxxxxxxx'cr''lf']
<add/RCDR_3_xxxxxx'cr'
>add/RCDR_3_xxxxxx'cr''lf']
<add/RCDR_3'cr'
>add/RCDR_3_xxxxxx'cr''lf']
<add/RCEN_4_xxxxxxxxxxx'cr'
>add/RCEN_4_xxxxxxxxxxx'cr''lf']
<add/RCEN_4'cr'
>add/RCEN_4_xxxxxxxxxxx'cr''lf']
<add/RCDR_4_xxxxxx'cr'
>add/RCDR_4_xxxxxx'cr''lf']
<add/RCDR_4'cr'
>add/RCDR_4_xxxxxx'cr''lf']
<add/RCCP_x_yyy'cr'
>add/RCCP_x_yyy'cr''lf']
<add/RCCP_x'cr'
>add/RCCP_x_yyy'cr''lf']
<add/RCDP_x_yyy'cr'
>add/RCDP_x_yyy'cr''lf']
<add/RCDP_x'cr'
>add/RCDP_x_yyy'cr''lf']
IRE_xxx'cr'
<add/RCSM_x'cr'
>add/RCSM_x'cr''lf']
<add/RCSM_'cr'
>add/RCSM_x'cr''lf']
Where: xxx = OFF (D&I Disabled)< ON (D&I Enabled).
This command enables channel #1 for D&I operation, or can
be disabled.
Where: xxx = OFF (ADPCM Disabled)< ON (ADPCM
Enabled).
This command enables channel #2 for ADPCM operation, or
can be disabled.
Where: xxxxxxxxxxx = OFF (Channel Disabled), AUPC
(Channel Enabled for AUPC), ASYNC_232 (Channel Enabled
for ASYNC RS232_, SYNC_RS232 (Channel Enabled for
SYNC RS232), ASYNC_RS422 (Channel Enabled for ASYNC
RS422), SYNC_RS422 (Channel Enabled for SYNC RS422).
This command enables channel #3 for SYNC/ASYNC
RS232/RS422 operation, AUPC operation, or can be disabled.
Where: xxxxxx = 0.6 to 4000.0 for RS422 (kbit/s in 100 bit/s
steps), 0.6 to 64.0 for RS232 (kbit/s in 100 bit/s steps).
Where: xxxxxxxxxxx = OFF (Channel Disabled), AUPC
(Channel Enabled for AUPC), ASYNC_RS232 (Channel
Enabled for ASYNC RS232), SYNC_RS232 (Channel Enabled
for SYNC RS232), ASYNC_RS485 (Channel Enabled for
ASYNC RS485).
This command enables channel #4 for SYNC/ASYNC RS232
operation, ASYNC RS485 operation, AUPC operation, or can
be disabled.
Where: xxxxxx = 0.6 to 64.0 (kbit/s in 100 bit/s steps).
Where:
x = 3 or 4 (channel number).
yyy = NRM (normal clock phasing), INV (inverted clock
phasing).
Where:
x = 3 or 4 (channel number).
yyy = NRM (normal clock phasing), INV (inverted clock
phasing).
Interface Read Error (RX 2047)
Where: x = 1, 2, 3, or 4 (channel number).
SDM-300A Satellite Modem
Rev. 4
