Remote Control Operation
Bulk Consol.
Status
(continued)
Notes:
1. Data will only be returned if TX Overhead is programmed for Drop & Insert. Comma is always returned.
2. Data will only be returned if RX Overhead is programmed for Drop & Insert. Comma is always returned.
3. Data will only be returned if TX Overhead is programmed for IDR. Comma is always returned.
4. Data will only be returned if RX Overhead is programmed for IDR. Comma is always returned.
5. Data will only be returned if TX Overhead is programmed for ASYNC. Comma is always returned.
6. Data will only be returned if RX Overhead is programmed for ASYNC. Comma is always returned.
7. Data is only returned if FLEX MUX PCB (Card Slot #1) is installed. Comma is always returned.
8. Data not returned if TX Channel #1 is disabled. Comma is always returned.
9. Data not returned if TX Channel #3 is disabled or set for AUPC. Comma is always returned.
10. Data not returned if TX Channel #4 is disabled or set for AUPC. Comma is always returned.
11. Data not returned if RX Channel #1 is disabled. Comma is always returned.
12. Data not returned if RX Channel #3 is disabled or set for AUPC. Comma is always returned.
13. Data not returned if RX Channel #4 is disabled or set for AUPC. Comma is always returned (except for last parameter).
14. Data will only be returned if TX Overhead is programmed for ASYNC. (or TX Flex Mux AUPC). Comma is always returned.
15. Data will only be returned if RX Overhead is programmed for ASYNC. (or RX Flex Mux AUPC). Comma is always returned.
B–46
SDM-300A Satellite Modem
Rev. 4
